Product Description

LX EA450 Circulation Pump with Optional Air Switch

The LX EA450 is a single-speed, 1.5 HP circulation pump designed for hot tubs and whirlpool baths, featuring an optional air switch for manual operation.

Specifications:

  • Motor Power: 1.5 HP (1.1 kW)
  • Current Draw: 5.8 A
  • Rotational Speed: 2,900 RPM
  • Plumbing Connections: 1.5-inch suction and discharge ports

Features:

  • Design: Centre discharge with self-draining capability
  • Construction: Thermally protected motor with a capacitor
  • Performance: Maximum flow rate of 360 L/min; maximum head of 16 m
  • Compatibility: Suitable for various spa brands, including Chinese-manufactured spas with 10–12 nozzles

This pump provides efficient and reliable operation for spa and whirlpool systems.

Product Attributes
Brand : LX
Product Type : Circulation Pump
Height : 255 mm
HP : 1.5HP
Length : 420mm
Power kW : 1.13 kW
Width : 185mm
Plumbing Size : 1.5"
Speeds : 1 speed
Amperage : 5.8 Amps
Product Attributes
Brand : LX
Product Type : Circulation Pump
Height : 255 mm
HP : 1.5HP
Length : 420mm
Power kW : 1.13 kW
Width : 185mm
Plumbing Size : 1.5"
Speeds : 1 speed
Amperage : 5.8 Amps
Product Description

LX EA450 Circulation Pump with Optional Air Switch

The LX EA450 is a single-speed, 1.5 HP circulation pump designed for hot tubs and whirlpool baths, featuring an optional air switch for manual operation.

Specifications:

  • Motor Power: 1.5 HP (1.1 kW)
  • Current Draw: 5.8 A
  • Rotational Speed: 2,900 RPM
  • Plumbing Connections: 1.5-inch suction and discharge ports

Features:

  • Design: Centre discharge with self-draining capability
  • Construction: Thermally protected motor with a capacitor
  • Performance: Maximum flow rate of 360 L/min; maximum head of 16 m
  • Compatibility: Suitable for various spa brands, including Chinese-manufactured spas with 10–12 nozzles

This pump provides efficient and reliable operation for spa and whirlpool systems.
